NetApp Disk Shelves and Storage Media
AFF and FAS systems
Step up to enterprise-grade infrastructure with disk shelves and storage media specifically designed for NetApp AFF and FAS systems.
Key Benefits
Disk shelves and storage media specifically designed for NetApp AFF and FAS systems help deliver the performance, resiliency, and flexibility your digital transformation needs.
Gain performance and capacity at every level
Explore a full range of disk shelves and storage media (SSD and HDD) to support your diverse business and application demands. These disk shelves are supported on AFF and FAS systems.
Realize enterprise-class resiliency
Keep constant access to your data. Hardware redundancy, NetApp RAID-DP and RAID-TEC for superior data protection, and Maintenance Center for advanced error recovery help make sure your data is always available.
Respond flexibly to business demands
Gain the flexibility you need with support for different shelves and media within a cluster—for example, AFF with SSDs and FAS with HDDs and SSDs. Max out your IT investment with support for multiple capacity points, types, and generations of shelves and media on your AFF and FAS systems. Focus on business—not technology issues.
Gain flexibility
Leverage NetApp drives and disk shelves across the ONTAP portfolio.
Optimize for performance and capacity
Choose the media to optimize your storage for performance and capacity, leveraging SSD and HDD.
Strengthen security
Enhance physical data security. Prevent unauthorized data access.
 |
 |
 |
 |
|
| NS224 | DS224C | DS212C | DS460C | |
|---|---|---|---|---|
| Rack units | 2U | 2U | 2U | 4U |
| Drives per enclosure | 24 | 24 | 12 | 60 |
| Drives per rack unit | 12 | 12 | 6 | 15 |
| Drive form factor | 2.5" small form factor | 2.5" small form factor | 3.5" large form factor | 3.5" large form factor |
| Drive carrier | Single drive | Single drive | Single drive | Single drive |
| High-capacity disk drives | N/A | N/A | 4TB, 8TB, 10TB, 16TB at 7.2K RPM | 4TB, 8TB, 10TB, 16TB at 7.2K RPM |
| Performance disk drives | N/A | 900GB, 1.2TB and 1.8TB at 10K RPM | N/A | N/A |
| Self-encrypting drives1 | AES-256 self-encrypting (SED) NVMe SSDs - 1.9TB, 3.8TB ,7 .6TB , 15.3TB AES-256 FIPS 140-2 compliant NVMe SSD 3.8TB, 15.3TB | 900GB and 1.8TB at 10K RPM, 800GB and 3.8TB SSD, 800GB SSD + 1.8TB at 10K RPM AES-256, FIPS 140-2 compliant | 6TB and 10TB at 7.2K RPM AES-256, FIPS 140-2 compliant | 10TB at 7.2K RPM AES-256, FIPS 140-2 compliant |
| Solid state drives (full and mixed shelf) | 1.9TB non-SED NVMe SSD, 3.8TB non-SED NVMe SSD | 960GB, 3.8TB, 15.3TB, 30TB, 960GB + 1.8TB, 7.6TB | 960GB + 4TB, 960GB + 8TB, 960GB + 10TB, 960GB + 16TB | 960GB + 4TB, 960GB + 8TB, 960GB + 10TB, 960GB + 16TB |
| Controller Support | AFF A900, AFF A800, AFF A700, AFF A400, AFF A320, AFF A250 | AFF A800, AFF A700, AFF A700s, AFF A400, AFF A300, AFF A220, AFF A250, AFF A200, AFF 8000 series, FAS9500, FAS9000, FAS8700, FAS8300, FAS8200, FAS8000 series, FAS2700, FAS2600 | FAS9500, FAS9000, FAS8700, FAS8300, FAS8200, FAS8000 series, FAS2700, FAS2600 | FAS9500, FAS9000, FAS8700, FAS8300, FAS8200, FAS8000 series, FAS2700, FAS2600 |
| Shelf I/O modules | Dual NSM modules (Ethernet Connections) | Dual IOM12 modules | Dual IOM12 modules | Dual IOM12 modules |
| Optical SAS support | N/A | ✓ | ✓ | ✓ |
| Power supply/cooling fans | Dual, hot-pluggable, integrated power supply/fan assemblies | Dual, hot-pluggable, integrated power supply/fan assemblies | Dual, hot-pluggable, integrated power supply/fan assemblies | Dual, hot-pluggable power supply; independent fan assemblies |
| AC input power voltage (autoranging, VRMS) | 100–120V or 200–240V | 100–120V or 200–240V | 200-240V | |
| AC input power frequency | 50–60 Hz | 50–60 Hz | ||
| DC input power | Not available | Not available | ||
| Weight—fully loaded | 62.2 lbs (28.2 kg) | 53.8 lbs (24.4 kg) | 60lbs (27.2 kg) | 246.9 lbs (112 kg) |
| Dimensions | Height: 3.4 in. (8.5 cm) Width: 19 in. (48.0 cm) Depth: 19.1 in. (48.4 cm) | Height: 3.4 in. (8.5 cm) Width: 19 in. (48.0 cm) Depth: 19.1 in. (48.4 cm) | Height: 3.4 in. (8.5 cm) Width: 19 in. (48.0 cm) Depth: 19.1 in. (48.4 cm) | Height: 7 in. (17.8 cm) Width: 19 in. (48.3 cm) Depth: 36 in. (91.4 cm) |
| Clearance dimensions | Front—cooling: 6 in. (15.3 cm) Front—maintenance: 12 in. (30.5 cm) Rear—cooling and maintenance: 25 in. (63.5 cm) | Front—cooling: 6 in. (15.3 cm) Front—maintenance: 12 in. (30.5 cm) Rear—cooling and maintenance: 25 in. (63.5 cm) | Front—cooling: 6 in. (15.3 cm) Front—maintenance: 12 in. (30.5 cm) Rear—cooling and maintenance: 25 in. (63.5 cm) | Front—cooling: 6 in. (15.3 cm) Front—maintenance: 30 in. (76 cm) Rear—cooling: 6 in. (15.3 cm) Rear—maintenance: 20 in. (50.8 cm) |
| Operating acoustic noise | 6.4 bels LwAd (2 PCMs) | 6.9 bels LwAd (2 PCMs) | 6.3 bels LwAd (2 PCMs) | 7.2 bels LwAd (2 PCMs) |
| Temperature | Operating: 50° F to 104° F (10° C to 40° C) Nonoperating: –40° F to 158° F (–40° C to 70° C) | |||
| Relative humidity | Operating: 20% to 80% noncondensing; Nonoperating: 10 to 95% noncondensing | |||
| Altitude | Operating: 0 to 10,000 ft (0 to 3,045 m) Nonoperating: –1,000 to 40,000 ft (–305 to 12,192 m) | |||
1 NSE relies on the drive manufacturer for assurance-level certification. Self-encrypting drives (SEDs) used with NetApp® Storage. Encryption (NSE) cannot be mixed with non-encrypting HDDs in the same storage system. MetroCluster is not supported with NSE.
